25KW Off Grid Solar Inverter
4500.00 - 4900.00 USD ($)
Product Details:
X
25KW Off Grid Solar Inverter Price And Quantity
- 4500.00 - 4900.00 USD ($)
- 1 Piece
25KW Off Grid Solar Inverter Trade Information
- Ningbo/Shanghai
- Paypal Western Union Letter of Credit at Sight (Sight L/C) Telegraphic Transfer (T/T)
- 1000 Piece Per Month
- 6-7 Days
- Yes
- Contact us for information regarding our sample policy
- Packing of 25KW Off Grid Solar Inverter is strong honeycomb carton
- Australia North America Eastern Europe Africa Western Europe Central America Middle East South America Asia
- All India
- CE(EMC&LVD), SAA(AS4777&AS3100), G83, G59, VDE ARN 4105, UL1741, CSA22.2, ISO9001
Product Description
We are backed by a capacious and contemporary infrastructural base, helps us in manufacturing and exporting Off Grid 25KW Solar Inverter. It has high efficiency and stable performance, with powerful protection function. To manufacture this inverter we use finest quality materials and components. Highly demanded in the market, this inverter comes in different specifications for clients. Off Grid 25KW Solar Inverter comes with caster wheels for smooth mobility. We offer this inverter at reasonable prices.
Features:
- Higher conversion efficiency
- Stable output voltage
- Can work without battery
Technical Specifications
| Model | SDP-25KW | ||||
| Isolation mode | Low Frequency Transformer | ||||
| DC Input | Rated voltage (Vdc) | 220V | 240V | ||
| Rated current(A) | 113.63A | 104A | |||
| AC Output | Rated output power | 25KW | |||
| Output waveform | Pure Sine Wave | ||||
| Rated Voltage | 220V+3% | 110/220VAC+3% | 380VAC+3% | ||
| Phases | Single phase | 2 phase 3 wire | 3 phase 4 wire | ||
| Rated current (A) | 113.63A | 113.63A (phase current) | 38A (phase current) | ||
| Frequency | 50Hz or 60Hz | ||||
| Rated output voltage | 110/120/220/230/240/380/400/415/440VAC optional | ||||
| Phases | Single / Two/ Three phase optional | ||||
| Power Factor (PF) | >0.95 | ||||
| Overload Ability | 150%, 5 seconds | ||||
| Efficiency | >94% | ||||
| Waveform distortion | <3%(Linear load) | ||||
| Dynamic Response | 5%, 50ms | ||||
| Display | LCD | ||||
| Running mode | Working continuously | ||||
| Electrical insulation | 2000Vac, 1 Minute | ||||
| AC Bypass Function | Optional | ||||
| Solar Charge Controller built in | Optional | ||||
| AC to DC battery Charger built in | Optional | ||||
| RS485 remote monitoring | Optional | ||||
| Wide voltage input 100-850VDC(optional) | Off grid inverter can work without battery | ||||
| Protection Function | Protection | Input reverse polarity, under voltage, overvoltage, Output over-current,short circuit, overheating etc. | |||
| Cooling method | Fan-cooled | ||||
| Short-circuit protection | No automatic recovery, need to restart the machine | ||||
| Working environment | Noise ( 1 meter) | 50dB | |||
| Degree of protection | IP20(indoor) | ||||
| Working Altitude (m) | 2000 | ||||
| Working temperature | -25~+55 | ||||
| relative humidity | 0~90%,non-condensing | ||||
| Mechanical dimension | Depth* Width * Height | 600x700x1000mm | |||
| Weight (Kg) | 250Kg | ||||
| Certification | European CE(EMC & LVD), SAA | ||||
